JGINYUE B550M PRO AM4 Motherboard, Support AMD Ryzen 4000 5000 CPU, Dual Channel DDR4 64GB Max XMP, 2 NVME M.2 + 4 SATA3.0, HDMI Dual DP, PCIe X16, USB 3.2/2.0 MATX Desktop Mainboard
New
SKU: 200007763:201336106
In stock
$137.00
✓ Secure checkout✓ Shipping updates✓ Customer support
✓
Product details
Specifications
SPECIFICATIONSApplication: Desktop,Laptop,Server,Workstation,Mining,Industrial ComputerBack I/O Ports: Displayport,HDMI 2.0Battery Included: YesBrand Name: JGINYUEChipset: AMD B550Chipset Manufacturer: AMDForm Factor: CeB,Micro-ATXHigh-concerned chemical: noneMaterial: othersMaximum Ram Capacity: 64 GBMemory channel: DoubleNumber Of Memory Slots: 2Number of PCI: 2Number of PCIe x 1: 1Number of PCIe x 16: 1Number of SATA Ports: 4Onboard LAN: 1x RJ45Origin: Mainland ChinaPCI - E standards: PCI-E 4.0Package: YesProcessor compatibility: AMD Ryzen 4000 Series-R3,AMD Ryzen 5000 Series-R5RAID Supported: YesSocket Type: AM4Special Features: NONEStorage Interface Type: SATA 3,M.2 (NVMe)Support Memory Type: DDR4Support USB Type: USB 2.0,USB 3.0Supports M.2 SSD: 2242,2280,2260Usage Scenario: Gaming,Audio & Video,Household,Office,Mini PC,others,HPCWith CPU: NoMotherboard modelB550M PROChipsetAMD B550 ChipsetCPU pinsSupports AMD AM4 4000 and 5000 series processorsMemory slot2 DDR4 memory slotsMemory capacityMaximum support for 64GB (32GB * 2)Memory frequencyDual channel support 2133/2400/2666/2800/3000/3200/3333/3466/3600/3733/3866/4000MHz (supports XMP technology/actual situation may vary depending on different CPU and memory configurations)Display interface1 HDMI, 2 DPStorage interface4 SATA3.0 6Gbps; 1 M.2 nvme protocol interface (directly connected to CPU automatic recognition 3.0 or 4.0), 1 M.2 nvme protocol 3.0 interfaceUSB interfaceRear 4 USB 3.2, 4 USB 2.0; Front mounted 1 USB 3.0 pin can expand 2 USB 3.2 pins, and 1 USB 2.0 pin can expand 2 USB 2.0 pinsPCIe interface1 PCI Express x16 slot (directly connected to CPU automatically recognized by CPU), 1 PCI Express x1 slotWireless interface1 WiFi interface (compatible with PCIe protocol)Onboard sound cardRealtek ALC897Onboard network cardRealtek 8111HPower socketMainboard powered by 24 pins, CPU powered by 8 pinsFan pin2 pieces with 4 needles, 2 pieces with 3 needlesNumber of power supply phases6-phase power supplySize specifications22cmx18cm M-ATXRGB pin4 RGB 5V3 pinssupport systemWindows10；Windows11Other interfaces1 one click BIOS clear button; 1 SPK1 buzzer pin
